Airtac SGJ Steel Tube Type Adjustable Cylinder SGJ125X150-20
$259.38
Regular price
$266.88
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SGJ125X150-20
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 15552 standard (formerly ISO 6431) for cylinder manufacturing;
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
Installation guidance:
Maximum side load capacity 150N. For vertical mounting,
use auxiliary support brackets when stroke exceeds 100mm.
Lubricate with ISO VG32 hydraulic oil if using non-lubricated air supply.
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
AirTAC SGJ Steel Tube Adjustable Cylinder SGJ125X150-20 Technical Details
- Full model: SGJ125X150-20
- Bore size: 125mm (precision honed steel tube)
- Stroke: 150mm (±0.5mm tolerance)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-700mm/s (lubricated condition)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/2 (NPT optional)
- Mounting type: Basic type (MF1)
- Rod end: External thread M30×1.5
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR + PU combination
- Weight: 6.8kg (without accessories)
- Dimensions: 330mm(L) × 140mm(W) × 140mm(H)
- Stroke tolerance adjustment: ±3° adjustable angle
- Optional accessories: Magnetic switch (D-A93 series), guide bush kit
Heavy-duty adjustable cylinder with chromium-plated piston rod (hardness HRC45-50) and anti-rotation mechanism. Features dual-layer sealing system with integrated wiper for contaminated environments. Requires ISO 8573-1:2010 [3:4:3] class compressed air.
Industrial Applications:
- Press machine ejection systems (die casting applications)
- Automated welding fixture positioning
- Paper converting equipment with precise stroke requirements
- Heavy-load conveyor diverters in logistics systems
- Plastic injection molding machine core pulling
Installation guidance:
Maximum side load capacity 150N. For vertical mounting,
use auxiliary support brackets when stroke exceeds 100mm.
Lubricate with ISO VG32 hydraulic oil if using non-lubricated air supply.
Cycle Life:
5,000km travel distance under standard conditions (0.5MPa, 25℃).
Recommend seal replacement after 3 million cycles in high-speed applications.
| Property | Property Value |
|---|---|
| sku | SGJ125X150-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 150mm |
