Airtac SGJ Steel Tube Type Adjustable Cylinder SGJ125X150-30
$259.38
Regular price
$266.88
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SGJ125X150-30
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 15552 standard (formerly ISO 6431) for cylinder manufacturing;
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
Maintenance Alert:
Perform monthly rod seal inspection when used in high-cycle applications (>500 cycles/hour).
Maintain air filtration at 5μm or finer. Avoid side load exceeding 200N during operation.
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
AirTAC SGJ Steel Tube Type Adjustable Stroke Cylinder SGJ125X150-30 Technical Details
- Model Code: SGJ125X150-30
- Bore Size: Ø125mm (ISO Standard)
- Stroke: 150mm (Adjustable with ±5mm precision)
- Operating Pressure: 0.05-1.2MPa
- Temperature Range: -20℃ to 80℃
- Cushioning Type: Rubber + Air Cushion (Adjustable)
- Mounting Style: Basic MF1 (Standard foot mount, optional flange/bracket)
- Port Size: Rc1/2 (NPT1/2 optional)
- Piston Rod Thread: M33×1.5 (External)
- Material: Cold Drawn Steel Tube (Hard Chrome Plated Rod)
- Seal Type: NBR + Special Wear Ring
- Weight: 8.7kg (Dry, without accessories)
- Dimensions:
- Length: 338mm (Min. retracted length)
- Width: 145mm (Body diameter with mounting flanges)
- Height: 165mm (Including piston rod protrusion)
- Sensor Compatibility: Built-in magnet for proximity sensor installation
- Protection Class: IP65 (Dust-tight & water jet resistant)
Industrial-grade adjustable stroke cylinder featuring heavy-duty steel construction with triple-layer chrome plating for enhanced corrosion resistance. The dual cushioning system allows precise end-position control, while the reinforced rod end withstands lateral forces up to 15% of maximum thrust. Requires ISO VG32 hydraulic oil mist lubrication (0.3-0.5cc/min recommended).
Industrial Applications:
- Die casting machine ejection systems
- Automotive assembly line clamping fixtures
- Sheet metal bending/stamping presses
- Heavy conveyor gate actuators
- Plastic injection molding machine core pulls
Maintenance Alert:
Perform monthly rod seal inspection when used in high-cycle applications (>500 cycles/hour).
Maintain air filtration at 5μm or finer. Avoid side load exceeding 200N during operation.
Optional Accessories:
Stroke adjustment lock nuts (P/N: SGJ-LK125), heat-resistant rod cover (200℃ version),
and magnetic sensor kits (DC/AC versions available)
| Property | Property Value |
|---|---|
| sku | SGJ125X150-30 |
| Adjustable Stroke | 30mm |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 150mm |
