Airtac SGJ Steel Tube Type Adjustable Cylinder SGJ125X160-10
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
AirTAC SGJ Series Steel Pipe Adjustable Cylinder SGJ125X160-10 Technical Details
- Model: SGJ125X160-10
- Type: Adjustable stroke steel pipe cylinder
- Bore size: 125mm
- Stroke: 160mm (adjustable)
- Mounting type: Basic type (MF1) with front flange
- Operating pressure: 0.05-1.0 MPa (7-145 psi)
- Cushioning: Adjustable pneumatic cushion
- Port size: Rc1/2 (NPT1/2 optional)
- Piston rod thread: M33×2.0
- Temperature range: -20℃ to 80℃
- Tube material: Cold drawn precision steel pipe
- Seal material: NBR + PU combination
- Protection rating: IP54 (standard wiper)
- Weight: 3.85kg (excluding accessories)
- Dimensions:
- Length: 348mm (min) / 508mm (max)
- Width: 175mm (flange mounting base)
- Height: 125mm (cylinder diameter)
Heavy-duty steel cylinder with precision-ground inner surface (Ra ≤0.4μm) for smooth operation. Features dual adjustable cushioning with 20° swivel adjustment screws and anti-rotation piston rod. Includes magnetic piston for position sensing compatibility. Designed for high side load applications with 2.5× safety factor on buckling resistance.
- Metal stamping press ejection systems
- Die-casting machine core pulling mechanisms
- Automated warehouse vertical lift positioning
- Paper converting equipment tension control
- Heavy-duty clamping fixtures in automotive welding lines
Installation recommendation:
Use with AIRTAC MAL series mounting brackets for optimal alignment.
Lubricate with ISO VG32 hydraulic oil if operating below -10℃.
Maximum side load capacity: 850N at full extension.
| Property | Property Value |
|---|---|
| sku | SGJ125X160-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 160mm |
