Airtac SGJ Steel Tube Type Adjustable Cylinder SGJ125X160-100
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
AirTAC SGJ125X160-100 Steel Pipe Adjustable Cylinder Specifications
- Model: SGJ125X160-100
- Type: Double-acting adjustable cushion cylinder (steel pipe structure)
- Bore size: 125mm
- Stroke: 160mm
- Operating pressure: 0.05–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Port size: G3/8 (ISO standard thread)
- Cushion type: Adjustable buffer at both ends
- Piston rod material: SCM435 chrome-plated steel
- Cylinder tube: Cold drawn precision steel pipe with hard chrome plating
- Seal material: NBR (nitrile rubber) with wear-resistant design
- Mounting style: Standard MF1 (front flange) & MB1 (rear foot) combo
- Weight: 16.8 kg (including mounting brackets)
- Dimensions:
- Extended length: 435±2mm
- Retracted length: 275±2mm
- Tube diameter: 146mm (outer diameter with mounting)
- Rod end thread: M56×2.0
Heavy-duty steel cylinder designed for high thrust applications requiring precise end-position damping control. Features triple sealing system with integrated wiper for harsh environments. The steel pipe construction provides 30% higher rigidity than standard aluminum cylinders, with corrosion-resistant plating for 5,000km+ service life.
- Metal stamping press ejection systems
- Automotive welding fixture positioning
- Injection molding machine core pulls
- Heavy conveyor gate actuators
- Paper processing machinery
Installation tip:
Use locknuts (ASNU125 model recommended) for rod-end load connections.
Adjust cushion needles gradually - turn 1/4 rotation per test cycle.
Lubricate with ISO VG32 hydraulic oil if operating below 0.3 MPa.
| Property | Property Value |
|---|---|
| sku | SGJ125X160-100 |
| Adjustable Stroke | 100mm |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 160mm |
