This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is SAUD32X25 — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the SAUD32X25 in place of this model. The SAU replacement uses the same profile body, bore, stroke, force and SC-series mounting. It moves to the current CMSG / DMSG / EMSG sensor switches (the SU used CS1-B / DS1-B) and adds the SAUF valve-integrated option.
Airtac SUD Series Double Rod Cylinder SUD32X25
The AirTAC Airtac SUD Series Double Rod Cylinder SUD32X25 is a double-acting profile-type standard cylinder with a Ø32mm bore and 25mm stroke, 1/8" air ports and adjustable end cushioning. This model is discontinued — the drop-in replacement is the SAUD32X25, which matches its bore, stroke, force and mounting.
- BoreØ32 mm
- Stroke25 mm
- Port size1/8"
- Acting typeDouble acting
- Rod threadM10×1.25
- StatusDiscontinued → SAUD32X25
About the Airtac SUD Series Double Rod Cylinder SUD32X25
The AirTAC SUD32X25 is a double-acting, double-rod profile cylinder that is officially discontinued. The exact drop-in replacement is the SAUD32X25, matching the 32mm bore, 25mm stroke, 1/8" port, and FA/LB mounting. Because a rod exits both ends, the push and pull forces are equal both ways at 345N @0.5 MPa, 483N @0.7 MPa, and 621N @0.9 MPa. The extruded aluminium profile barrel is shorter than an ISO 15552 cylinder of the same bore.
With equal force both ways, the back rod can drive a second tool or carry a sensor cam while resisting rotation. This non-magnet SKU cannot take a switch (legacy CS1-B/DS1-B sensors were used on the -S version; the SAUD uses CMSG/DMSG/EMSG). For sizing, the safe working load is ~207N (60% of the 345N @0.5 figure), yielding a vertical lift capacity of ~18kg with a 2:1 margin. Note that air cushions only decelerate; use an external rod lock for load holding.
Airtac SUD Series Double Rod Cylinder SUD32X25 Technical Specifications
| Model | Airtac SUD Series Double Rod Cylinder SUD32X25 |
|---|---|
| Series | SU profile-type cylinder (discontinued) |
| Replacement | SAUD32X25 |
| Bore size | Ø32 mm |
| Stroke | 25 mm |
| Acting type | Double acting |
| Port size | 1/8" |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 21 mm |
| Max standard stroke | Up to 1000 mm |
Specifications follow the official AirTAC SU datasheet (now discontinued). The SAUD32X25 carries the same ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
The SAUD32X25 produces the same force from the same bore — a true drop-in on output. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SUD Series Double Rod Cylinder SUD32X25
| SU | Profile-type standard cylinder (discontinued). |
|---|---|
| 32 | Bore size in mm. |
| ×25 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SU-family variants: SUD (double rod), SUJ (adjustable stroke) — each maps to its SAU equivalent (SUD→SAUD, SUJ→SAUJ). The current SAU line adds the SAUF valve-integrated option.
Where the Airtac SUD Series Double Rod Cylinder SUD32X25 Is Used
Dual-Tool Machining Station
Drives two opposing tools simultaneously using both rod ends, ensuring perfectly synchronized machining with equal push and pull force.
Anti-Rotation Transfer Gate
Uses the double-rod geometry to prevent piston rotation during lateral product transfers on a tight-profile conveyor line.
Compact Pinning Press
Presses pins from both sides in a confined space, relying on the short profile barrel and equal both ways force for balanced insertion.
Replacing the Airtac SUD Series Double Rod Cylinder SUD32X25 with the SAUD32X25
To replace this discontinued model, order the SAUD32X25 drop-in, which matches the 32mm bore, 25mm stroke, 1/8" port, and FA/LB mounts. Size both ways by checking neighbouring bores if you need more or less equal force. A double rod is right when you need anti-rotation or a back rod for a sensor cam. If upgrading from a -S SUD to an SAUD, change to CMSG/DMSG/EMSG sensors. For strokes >=300, verify side-load limits. Air cushions only decelerate; use an external rod lock for load holding.
Replacement checklist
- ✓ Same bore / stroke → SAUD32X25
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S): sensor family CS1-B → CMSG
- ✓ Mounting reused (FA/FB/CA/CB/LB)
- ✓ Need a built-in valve? → SAUF
Airtac SUD Series Double Rod Cylinder SUD32X25 FAQ
Yes, the SUD32X25 is discontinued. The exact drop-in replacement is the SAUD32X25, which matches the 32mm bore, 25mm stroke, 1/8" port, and FA/LB mounting.
The 1/8" port cylinder delivers equal force both ways: 345N @0.5 MPa, 483N @0.7 MPa, and 621N @0.9 MPa. It never quotes a larger single-rod push value.
