Airtac SULF Front Locking Cylinder SULF100X100
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF100X100 Front Lock Type Cylinder Specifications
- Model: SULF100X100
- Type: Double-acting cylinder with mechanical front lock
- Bore size: Ø100 mm
- Stroke: 100 mm (Customizable: 25-500 mm)
- Operating pressure: 0.15-1.0 MPa
- Cushioning: Adjustable hydraulic buffer + rubber pad
- Locking force: 3,800 N (at 0.5 MPa)
- Mounting type: Basic MF1 (ISO/VDMA compatible)
- Piston rod material: Hard chrome-plated SCM435 steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Temperature range: -20℃ to 80℃
- Protection rating: IP65 (rod side)/IP54 (tube side)
- Weight: 8.5 kg (standard stroke)
- Dimensions: 300mm(L) × 100mm(W) × 100mm(H)
Heavy-duty locking cylinder featuring dual safety mechanism with mechanical lock and pneumatic interlock. The enhanced rod end design withstands 150% side load capacity compared to standard models. Requires 5μm filtered lubricated air (ISO8573-1 class 3-4-3) and periodic lubrication cycle every 3,000 km travel distance.
- Press machine safety interlock systems
- Automated warehouse vertical load positioning
- Die-casting mold clamping security
- Elevator emergency braking mechanisms
- Robotic welding fixture position retention
Installation note:
Lock mechanism requires manual release via emergency unlock lever before initial operation.
Maintain 0.5mm minimum clearance between lock collar and mounting surface. Perform weekly lock
engagement force checks using torque wrench (18-22 N·m specification).
| Property | Property Value |
|---|---|
| sku | SULF100X100 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
| Lock Position | Front Cover with Lock |
