Airtac SULF Front Locking Cylinder SULF100X100-S
$195.64
Regular price
$203.14
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SULF100X100-S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Locking cylinder configurations include: Front-end locking type and Rear-end locking type;
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
Installation note:
Maintain 0.5-1mm clearance between lock unit and mounting surface.
Perform weekly lubrication via built-in grease nipple (M6×1).
Do NOT exceed 1,200mm/s piston speed during unlocking phase.
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF100X100-S Rod Lock Cylinder Specifications
- Model: SULF100X100-S
- Type: Double-acting cylinder with mechanical rod lock
- Bore size: Ø100mm
- Stroke: 100mm (Customizable: 25-500mm)
- Operating pressure: 0.2-1.0 MPa
- Locking force: 7,850N (at 0.5MPa)
- Actuation direction: Bidirectional locking
- Cushioning type: Adjustable rubber buffer + external shock absorber
- Mounting style: MF1 (Standard flange mounting)
- Port size: G3/8 (BSPP thread)
- Seal material: Polyurethane (PU) + NBR hybrid
- Temperature range: -10℃ to 80℃
- Protection rating: IP54 (standard), IP67 optional
- Weight: 5.8kg (bare cylinder), 6.3kg (with accessories)
- Dimensions: 400mm(L) × 100mm(W) × 100mm(H) (at mid-stroke)
Heavy-duty locking cylinder featuring fail-safe mechanical brake mechanism with dual piston rod clamps. Integrated position detection slots (ISO 6432 compatible) and corrosion-resistant hard anodized barrel. Requires 15μm filtered lubricated air (ISO 8573-1:2010 Class 4).
Typical Applications:
- Vertical load holding in automated assembly lines
- Emergency stop positioning in material handling systems
- Press machine safety interlocks
- Overhead crane brake systems
- Robotic welding fixture clamping
Installation note:
Maintain 0.5-1mm clearance between lock unit and mounting surface.
Perform weekly lubrication via built-in grease nipple (M6×1).
Do NOT exceed 1,200mm/s piston speed during unlocking phase.
| Property | Property Value |
|---|---|
| sku | SULF100X100-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
| Lock Position | Front Cover with Lock |
