Airtac SULF Front Locking Cylinder SULF100X1000
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF100X1000 Front Lock Cylinder Technical Details
- Model: SULF100X1000
- Type: Double-acting with mechanical lock (front position)
- Bore size: Ø100mm
- Stroke: 1000mm
- Operating pressure: 0.2–1.0 MPa
- Lock holding force: 18,000N (max)
- Cushioning: Adjustable elastic cushion + shock absorber
- Mounting type: MF1 (basic front flange)
- Port size: G3/8 (dual ports)
- Lock mechanism: Dual piston wedge system
- Rod material: Chrome-plated steel (Cr-Mo)
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU hybrid seals
- Ambient temperature: -20℃ to +80℃
- Weight: 15.8kg (excluding accessories)
- Dimensions: 1200mm(L) × 120mm(W) × 120mm(H)
- Protection rating: IP67 (rod extended)
- Lubrication: Pre-lubricated (Grease-free operation)
Heavy-duty locking cylinder with fail-safe position retention, featuring dual wedge locking pistons that mechanically lock the rod at full extension. Designed for vertical applications requiring position hold under load loss. Integrated shock absorption reduces end-impact by 60% compared to standard models. Requires 5μm filtered air with 1-10mg/m³ lubricant (ISO 8573-1:2010 Class 4).
- Press machine safety interlocks
- Overhead crane brake systems
- Automotive welding fixture position locks
- Foundry equipment mold clamping
- Warehouse vertical lift position retention
Installation criticals:
Must maintain ≤0.5mm/m alignment tolerance during mounting.
Lock engagement requires minimum 0.5MPa pressure.
For vertical use, install manual release lever (optional accessory ASF-100L)
for emergency unlocking.
| Property | Property Value |
|---|---|
| sku | SULF100X1000 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
| Lock Position | Front Cover with Lock |
