Airtac SULF Front Locking Cylinder SULF100X1000S
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF100X1000S Front Lock Cylinder Specifications
- Model: SULF100X1000S
- Type: Double-acting cylinder with mechanical front lock
- Bore size: 100mm (ISO standard)
- Stroke: 1000mm (adjustable cushioning)
- Operating pressure: 0.05–1.0 MPa
- Locking force: ≥6500N (at 0.5MPa)
- Piston speed: 50–800mm/s
- Port size: G3/8 (NPT1/2 optional)
- Rod diameter: 35mm (chrome-plated)
- Seal material: Polyurethane (NBR optional)
- Temperature range: -10℃ to 80℃
- Protection rating: IP67 (wipers included)
- Weight: 12.8kg (excluding accessories)
- Dimensions: 1290mm(L) × 156mm(W) × 156mm(H)
Heavy-duty locking cylinder with fail-safe mechanical brake mechanism, featuring precision ground stainless steel guide rods and dual-position sensor slots. The integrated lock maintains position during power loss, with wear-resistant brass brake shoes. Requires 40μm filtered air and ISO VG32 hydraulic oil lubrication.
- Press machine safety clamping systems
- Automotive welding fixture position retention
- Overhead crane emergency braking
- Injection molding machine core pulls
- Elevator door locking mechanisms
Installation note:
Mount horizontally with ±2° tolerance. Apply 0.1-0.3mm molybdenum disulfide grease to lock slides monthly.
Allow 50mm clearance behind cylinder for maintenance access.
| Property | Property Value |
|---|---|
| sku | SULF100X1000S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
| Lock Position | Front Cover with Lock |
