Airtac SULF Front Locking Cylinder SULF100X150
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF Series Front Locking Cylinder SULF100X150 Technical Details
- Model: SULF100X150
- Type: Double-acting cylinder with mechanical locking mechanism
- Bore size: 100mm
- Stroke: 150mm (±0.5mm tolerance)
- Operating pressure: 0.2–1.0 MPa
- Locking force: ≥1,200N (at 0.5MPa)
- Port size: G3/8 (NPT1/2 optional)
- Cushioning type: Adjustable rubber buffer + air cushion
- Temperature range: -20℃ to 80℃
- Cylinder tube material: Aluminum alloy with hard anodization
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Seal material: NBR/PU compound seals
- Protection rating: IP54 (standard), IP67 (optional)
- Weight: 5.8kg (excluding accessories)
- Dimensions: 350mm(L) × 125mm(W) × 125mm(H)
- Mounting: Standard ISO/VDMA front flange (MF1) & rear foot (FE)
High-precision locking cylinder featuring dual-position mechanical brake system with spring-engaged wedge mechanism. The corrosion-resistant design incorporates wear-compensating seals and anti-rotation guide bushings, ensuring ≤0.1mm repeat positioning accuracy. Requires filtered lubricated air (ISO 8573-1 class 3.4.3) with 10-20 cSt oil viscosity.
- Vertical load holding in automated assembly lines
- Emergency stop positioning in material handling systems
- Precision clamping fixtures for CNC machining centers
- Overhead lifting equipment safety brakes
- Press machine mid-stroke position retention
Installation note:
Locking mechanism requires manual release via emergency unlock screw (M8×1.25) before initial operation.
Maintain horizontal mounting orientation (±3° tolerance) and perform weekly lubrication through AUX1 grease port.
| Property | Property Value |
|---|---|
| sku | SULF100X150 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 150mm |
| Lock Position | Front Cover with Lock |
