Airtac SULF Front Locking Cylinder SULF100X150S
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF100X150S Front Lock Cylinder Technical Details
- Model: SULF100X150S
- Type: Double-acting pneumatic cylinder with mechanical lock
- Bore size: Ø100mm
- Stroke: 150mm
- Operating pressure: 0.1–0.8 MPa
- Locking mechanism: Spring-assisted mechanical brake
- Port size: G3/8 (NPT1/2 optional)
- Cushioning: Adjustable air cushion (both ends)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy barrel, CRCA mounting brackets
- Surface treatment: Hard anodized piston rod
- Seal material: NBR (nitrile rubber)
- Protection rating: IP65 (standard), IP67 (optional)
- Weight: 9.8kg ±2% (excluding accessories)
- Dimensions: 338mm(L) × 128mm(W) × 128mm(H) (fully extended)
- Rod thread: M20×1.5 (external)
- Mounting type: Basic/Foot-MA1, Front flange-MF2, Rear flange-MF1
Heavy-duty locking cylinder with fail-safe position retention capability, featuring dual-position mechanical locking that engages automatically at stroke ends. The chrome-plated piston rod with wear-resistant guide rings ensures smooth operation under lateral loads. Requires 5-40μm filtered lubricated air (ISO 8573-1 class 4).
- Vertical load holding in automated assembly lines
- Safety positioning in press brake tooling systems
- Palletizing robot end-effector locking
- Mold clamping in plastic injection machines
- Emergency stop positioning in material handling
Installation note:
Locking engagement requires minimum 0.3MPa air pressure. For vertical mounting,
use auxiliary support brackets (ASF-100 kit recommended). Lubricate piston rod
weekly with ISO VG32 hydraulic oil when operating in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | SULF100X150S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 150mm |
| Lock Position | Front Cover with Lock |
