Airtac SULF Front Locking Cylinder SULF100X175
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF100X175 Front Lock Cylinder Specifications
- Model: SULF100X175
- Type: Double-acting cylinder with mechanical lock
- Bore size: Ø100 mm
- Stroke: 175 mm
- Operating pressure: 0.05–1.0 MPa
- Lock holding force: 4,500 N (max)
- Port size: G3/8 (NPT1/2 optional)
- Cushioning: Adjustable air cushion
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–700 mm/s
- Body material: Aluminum alloy (anodized)
- Rod material: Chrome-plated steel
- Seal material: NBR/PU (standard), optional FKM
- Weight: 8.7 kg (with lock mechanism)
- Dimensions: 318mm(L) × 130mm(W) × 130mm(H)
- Mounting type: Standard ISO/VDMA front flange (MF1)
- Protection rating: IP67 (wipers included)
Heavy-duty locking cylinder with fail-safe mechanical brake system, featuring dual-stage locking mechanism for vertical load applications. The integrated position sensor groove (ISO 9409-1) enables easy feedback device installation. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.3 quality.
- Vertical press machine safety brakes
- Automated warehouse elevator positioning
- Die-casting machine mold locking
- Solar panel tilt adjustment mechanisms
- Robotic welding fixture stabilization
Installation note:
Lock mechanism requires manual release via side lever during maintenance.
Lubricate with ISO VG32 turbine oil (Nippon Mistubishi PAG UCON LB-1002-X1 equivalent recommended).
| Property | Property Value |
|---|---|
| sku | SULF100X175 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 175mm |
| Lock Position | Front Cover with Lock |
