Airtac SULF Front Locking Cylinder SULF100X200
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF Series Front Lock Cylinder SULF100X200 Technical Details
- Model: SULF100X200
- Type: Double-acting cylinder with mechanical locking
- Bore size: Ø100mm
- Stroke: 200mm
- Operating pressure: 0.15–1.0 MPa
- Locking method: Wedge-type mechanical lock (front position)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting: Standard MF1 flange mounting
- Port size: G3/8 (NPT1/2 optional)
- Temperature range: -20℃ to 80℃
- Seal material: HNBR (hydrogenated nitrile) with wear-resistant ring
- Rod material: Chrome-plated carbon steel
- Weight: 3.8kg (excluding accessories)
- Dimensions: 300mm(L) × 128mm(W) × 128mm(H) (full extension)
Heavy-duty locking cylinder featuring fail-safe position retention with ±0.2mm repeatability. The dual-piston design enables 2,500N locking force at 0.5MPa. Integrated wear sensors (optional) and IP54-rated construction make it suitable for harsh environments. Requires 20μm filtered air with ISO VG32 lubricant.
- Press machine safety interlocks
- Automated welding positioners
- Elevator emergency braking systems
- Die-casting mold clamping mechanisms
- Satellite antenna positioning locks
Installation protocol:
Lock engagement requires 0.3MPa minimum pressure. Always disengage lock before manual override.
Lubricate guide shafts every 500km of cumulative travel.
| Property | Property Value |
|---|---|
| sku | SULF100X200 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <200mm> |
| Lock Position | Front Cover with Lock |
