Airtac SULF Front Locking Cylinder SULF100X400
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF100X400 Front Lock Cylinder Specifications
- Model: SULF100X400
- Type: Double-acting cylinder with mechanical lock
- Bore size: Ø100 mm
- Stroke: 400 mm
- Operating pressure: 0.15–0.8 MPa
- Locking method: Manual release lever with spring return
- Lock holding force: 3,500 N (at 0.5 MPa)
- Cushioning: Adjustable pneumatic cushion at both ends
- Port size: G1/2 (NPT1/2 optional)
- Temperature range: -20℃ to 80℃
- Body material: Anodized aluminum alloy
- Rod material: Chrome-plated steel
- Seal material: NBR + PU hybrid
- Protection rating: IP67 (rod extended)
- Weight: 5.8 kg (excluding accessories)
- Dimensions: 540mm(L) × 100mm(W) × 100mm(H)
Heavy-duty locking cylinder with fail-safe mechanical position retention, featuring dual-stage sealing for leak prevention. The integrated lock mechanism engages automatically at stroke ends or manually via lever, providing 360° directional holding force. Requires 0.5μm filtered air with ISO VG32 lubricant (optional oil mist lubrication).
- Press machine safety interlocks
- Automated welding positioners
- Elevator emergency braking systems
- Mold clamping mechanisms
- Material handling vertical load locks
Installation note:
Lock engagement requires 0.3MPa minimum pressure. For vertical mounting,
install lock mechanism downward. Lubricate guide shafts every 500km stroke
using ISO VG68 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | SULF100X400 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <400mm> |
| Lock Position | Front Cover with Lock |
