Airtac SULF Front Locking Cylinder SULF40X120
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF40X120 Front Lock Cylinder Technical Specifications
- Model: SULF40X120
- Type: Double-acting pneumatic cylinder with mechanical front lock
- Bore size: 40mm
- Stroke: 120mm
- Operating pressure: 0.1-0.8 MPa
- Locking mechanism: Spring-assisted mechanical brake (front position)
- Port size: 1/4" NPT (G1/8 optional)
- Cushioning: Adjustable pneumatic cushion at both ends
- Temperature range: -20℃ to 80℃
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated stainless steel (SUS304)
- Seals: NBR (Nitrile rubber)
- Weight: 2.8kg ±5%
- Dimensions: 220mm(L) × 40mm(W) × 60mm(H) (excluding mounting accessories)
- Rod thread: M10×1.25
- Protection class: IP54 (standard), IP67 (optional)
Industrial-grade locking cylinder featuring instant position holding capability through its integrated front mechanical brake. The dual-piston locking design ensures zero drift under load when de-energized. Optimized for vertical applications requiring fail-safe position retention, with corrosion-resistant construction for harsh environments. Requires 5-40μm filtered air with ISO VG32 lubricant.
- Vertical lifting systems in automated assembly lines
- Safety clamping devices in press machinery
- Position retention in material handling robots
- Stage equipment positioning in entertainment systems
- Emergency stop mechanisms in conveyor systems
Installation guidelines:
Locking function activates only at stroke end. Maintain minimum 0.3MPa pressure for proper brake release.
Avoid side loads exceeding 30N. Recommended lubrication interval: 3 months continuous operation.
| Property | Property Value |
|---|---|
| sku | SULF40X120 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 120mm |
| Lock Position | Front Cover with Lock |
