Airtac SULF Front Locking Cylinder SULF40X120-S
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF40X120-S Front Locking Cylinder Specifications
- Model: SULF40X120-S
- Type: Double-acting cylinder with mechanical locking mechanism
- Bore size: 40mm
- Stroke: 120mm
- Operating pressure: 0.1–0.8 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Mounting style: Front flange with integrated lock nut (ISO 15552 standard)
- Port size: G1/8 (NPT optional)
- Operating temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Weight: 1.8kg ±3%
- Dimensions: 160mm(L) × 48mm(W) × 48mm(H) (excluding rod extension)
- Total extended length: 280mm (stroke fully extended)
- Locking force: 850N max @ 0.6MPa
- Protection rating: IP65 (standard), IP67 (optional)
- ISO compatibility: Compliant with ISO 15552 (VDMA 24562)
Heavy-duty locking cylinder featuring fail-safe position retention through integrated mechanical brake. The dual-piston locking mechanism ensures zero drift under load, with corrosion-resistant construction for harsh environments. Requires 5-40μm filtered air and periodic lubrication (ISO VG32 hydraulic oil recommended). Includes magnetic piston for position sensing compatibility.
- Vertical load holding in automated assembly lines
- Safety clamping in press brake operations
- Position locking in material handling elevators
- Precision fixturing for CNC machining centers
- Emergency stop systems in automotive tooling
Installation note:
Engage locking mechanism only at full stroke positions. Allow 0.5-1 second dwell time before activation.
Maintain 20mm minimum clearance around cylinder body for heat dissipation. Align rod axis within ±2° of load direction.
- Lock activation pressure: 0.3MPa minimum
- Response time (lock engagement): ≤0.3 seconds
- Max lateral load: 150N at piston rod end
- Service interval: 2,000km travel or 12 months
| Property | Property Value |
|---|---|
| sku | SULF40X120-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | 120mm |
| Lock Position | Front Cover with Lock |
