Airtac SULF Front Locking Cylinder SULF40X30
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF40X30 Front Lock Cylinder Specifications
- Model: SULF40X30
- Type: Double-acting cylinder with mechanical front lock
- Bore size: 40mm
- Stroke: 30mm (Standard) | Custom strokes: 10-300mm
- Operating pressure: 0.05-1.0 MPa
- Locking force: ≥350N at 0.5MPa
- Mounting style: ISO/VDS Standard flange Mounting
- Port size: M5x0.8 (G1/8 adaptor optional)
- Cushioning: Adjustable elastic cushion + shock absorber
- Temperature range: -20℃ to 80℃
- Barrel material: Aluminum alloy (Anodizing)
- Piston rod: Chrome-plated stainless steel (SUS304)
- Seal material: NBR (oil-resistant wear-resistant formula)
- Protection rating: IP54 (standard dust-proof seals)
- Weight: 0.98kg ±5% (excluding mounting accessories)
- Dimensions: Overall length 153mm (at 30mm stroke) | Flange mounting face 60×60mm | Piston rod end thread M10×1.25
Industrial-grade locking cylinder featuring dual safety mechanism: spring-assisted mechanical lock + pneumatic interlock. The hardened guide bushing ensures precise alignment under side loads. Requires 5μm filtered lubricated air (ISO 8573-1 compliant). Optional magnetic sensor slots (M8/M5) for position feedback.
- Vertical load holding in material handling systems
- Emergency stop positioning in injection molding machines
- Tooling fixture locking in CNC rotary tables
- Overhead conveyor safety brakes
- Robotic welding positioner stabilization
Installation protocol: Locking mechanism requires manual release via 3mm hex key before initial operation.
Maintain 0.3-1.0MPa residual pressure during locking engagement. Lubricate weekly with ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | SULF40X30 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 30mm |
| Lock Position | Front Cover with Lock |
