Airtac SULF Front Locking Cylinder SULF50X10
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF50X10 Front Lock Cylinder Specifications
- Model: SULF50X10
- Type: Double-acting cylinder with mechanical lock
- Bore size: Ø50 mm
- Stroke: 10 mm (standard stroke)
- Operating pressure: 0.1–1.0 MPa
- Locking force: 1,500 N (at 0.5 MPa)
- Lock type: Spring-assisted mechanical lock
- Port size: G1/8 (NPT1/8 optional)
- Cushioning: Adjustable pneumatic cushion
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body, CRMo steel piston rod
- Rod surface treatment: Hard chrome plating (20-25μm)
- Seal material: NBR (nitrile rubber)
- Weight: 1.8 kg ±5%
- Dimensions:
- Cylinder length: 98 mm
- Lock unit length: 32 mm
- Total length (extended): 130 mm
- Mounting base: 60×60 mm square
- Rod diameter: Ø16 mm
Precision lock cylinder featuring fail-safe mechanical braking, designed for vertical load holding and position retention. The dual-chamber lock mechanism engages automatically during pressure loss, with 0.5mm maximum position deviation. Includes wear-resistant guide bushings and IP54-rated dust protection.
- Vertical press machine safety brakes
- Automated welding fixture position locking
- Elevator emergency stop systems
- CNC tool changer arm stabilization
- Overhead conveyor pause mechanisms
Installation notes:
- Requires minimum 0.3 MPa unlocking pressure
- Lubricate with ISO VG32 hydraulic oil
- Max lateral load: 200 N at rod end
- For vertical use only (rod facing downward)
| Property | Property Value |
|---|---|
| sku | SULF50X10 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <10mm> |
| Lock Position | Front Cover with Lock |
