Airtac SULF Front Locking Cylinder SULF50X100-S
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF50X100-S Front Lock Cylinder Technical Details
- Model: SULF50X100-S
- Bore size: Ø50 mm
- Stroke: 100 mm
- Operating pressure: 0.1–0.8 MPa
- Locking force: 1,800 N (at 0.5 MPa)
- Lock type: Dual-piston mechanical lock (spring applied/pressure released)
- Piston speed: 50–800 mm/s
- Buffer type: Adjustable hydraulic cushioning
- Mounting style: Standard ISO 15552 foot & flange mounts
- Port size: G1/8 (NPT1/4 optional)
- Ambient temperature: -20℃ to 80℃
- Seal material: Heat-resistant NBR (+5℃ to +100℃)
- Repeat positioning accuracy: ±0.5 mm
- Weight: 2.8 kg (excluding accessories)
- Dimensions: 300mm(L) × 84mm(W) × 84mm(H) (full extension)
- Rod thread: M16×1.5
- ISO standard: 15552 (formerly ISO 6431)
Heavy-duty lock cylinder with fail-safe position retention, featuring dual internal locking pistons that engage automatically upon pressure loss. The hardened chrome-plated piston rod and self-lubricating guide rings ensure smooth operation in high-side-load applications. Requires 5-40μm filtered air with ISO VG32 lubricator.
- Vertical load securing in automated assembly lines
- Emergency stop position holding in press machinery
- Workpiece clamping in CNC machining centers
- Overhead load stabilization in material handling systems
- Safety interlocks in automotive welding robots
Installation protocol:
Maintain ≤0.3mm alignment tolerance during mounting. Perform lock engagement test
at 0.3 MPa before full operation. Lubricate lock mechanism every 500km of travel
using ISO VG32 oil. Requires 2mm minimum clearance around lock housing for thermal expansion.
| Property | Property Value |
|---|---|
| sku | SULF50X100-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
| Lock Position | Front Cover with Lock |
