Airtac SULF Front Locking Cylinder SULF50X125-S
$103.10
Regular price
$110.60
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SULF50X125-S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Locking cylinder configurations include: Front-end locking type and Rear-end locking type;
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
Operational guidance:
Engage lock only when cylinder is fully extended. Perform monthly lubrication
of locking mechanism with ISO VG32 hydraulic oil. Avoid side-load forces
exceeding 30N during locking operation.
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF50X125-S Front Mechanical Lock Cylinder Specifications
- Model: SULF50X125-S
- Type: Double-acting cylinder with front mechanical locking mechanism
- Bore size: Ø50 mm
- Stroke: 125 mm
- Operating pressure: 0.05–0.8 MPa
- Port size: G1/8 (NPT1/8 optional)
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Rod material: Hard chrome-plated stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Ambient temperature: -20℃ to +80℃
- Locking force: 1,200 N (at 0.5 MPa)
- Weight: 2.8 kg (excluding accessories)
- Dimensions: 200mm(L) × 50mm(W) × 50mm(H) (retracted position)
- Mounting style: Standard ISO 15552 front flange with 4×M6 threads
- Protection rating: IP67 (wipers included)
- Piston speed: 50–800 mm/s
Industrial-grade locking cylinder featuring fail-safe position retention through its spring-activated mechanical lock. The chrome-plated rod and triple-lip wiper seal ensure durability in high-cycle applications. Requires 5-40 μm filtered air with ISO 8573-1:2010 class 4.2.3 quality.
Typical Applications:
- Vertical load positioning in automated assembly lines
- Safety braking in material handling elevators
- Tooling fixture lockdown in CNC machining centers
- Emergency stop mechanisms for robotic arms
- Press machine intermediate position holding
Operational guidance:
Engage lock only when cylinder is fully extended. Perform monthly lubrication
of locking mechanism with ISO VG32 hydraulic oil. Avoid side-load forces
exceeding 30N during locking operation.
| Property | Property Value |
|---|---|
| sku | SULF50X125-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 125mm |
| Lock Position | Front Cover with Lock |
