Airtac SULF Front Locking Cylinder SULF50X50
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF Series Front Lock Cylinder SULF50X50 Technical Details
- Model: SULF50X50
- Bore size: Ø50 mm
- Stroke: 50 mm (Customizable: 25-500 mm)
- Operating pressure: 0.1-1.0 MPa
- Locking force: 1,250 N (at 0.5 MPa)
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (dual side)
- Lock mechanism: Mechanical wedge-type front lock
- Mounting type: ISO 15552 standard (pre-drilled mounting holes)
- Port size: G1/4 (NPT1/4 optional)
- Rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy with hard anodizing
- Seal material: NBR (Nitrile rubber)
- Weight: 3.2 kg (standard stroke)
- Dimensions (L×W×H): 230mm × 50mm × 50mm (excluding rod)
- Rod end thread: M16×1.5
- Protection class: IP65 (Dust-tight & water jet resistant)
High-precision locking cylinder featuring instantaneous position retention upon air pressure loss. The wedge-lock mechanism provides zero-backlash holding force (3x stronger than standard magnetic locks). Precision-ground rod surface (Ra≤0.4μm) ensures smooth operation with ≤0.1mm repeat positioning accuracy. Integrated shock absorbers reduce end-impact noise by 15dB.
- Vertical load holding in CNC tool changers
- Safety braking in automated material handling systems
- Position retention in semiconductor wafer handling robots
- Emergency stop mechanisms for press machines
- Precision fixturing in optical component manufacturing
Installation protocol:
Requires weekly lubrication (ISO VG32 oil mist). Lock engagement time must not exceed 72 hours continuously.
For vertical mounting, install auxiliary rod support when handling loads >200kg.
| Property | Property Value |
|---|---|
| sku | SULF50X50 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <50mm> |
| Lock Position | Front Cover with Lock |
