Airtac SULF Front Locking Cylinder SULF50X75
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF Series Front Lock Cylinder SULF50X75 Technical Details
- Model: SULF50X75
- Type: Double-acting cylinder with mechanical front lock
- Bore size: Ø50 mm
- Stroke: 75 mm
- Operating pressure: 0.1–0.8 MPa
- Locking force: 1,470 N (at 0.5 MPa)
- Lock mechanism: Spring-assisted mechanical brake
- Mounting style: Basic type (MF1) / Flange options available
- Cushioning: Adjustable pneumatic cushion
- Temperature range: -20℃ to 80℃
- Port size: G1/4 (ISO standard)
- Material: Aluminum alloy barrel, hardened stainless steel piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 3.2 kg ±5%
- Dimensions: 240mm(L) × 50mm(W) × 50mm(H) (excluding mounting accessories)
- Rod thread: M16×1.5
- Max piston speed: 500 mm/s
- ISO standard: 15552
Industrial-grade locking cylinder featuring instant position-holding capability through integrated mechanical braking. The dual-safety design combines pneumatic holding force with physical locking, preventing unintended movement during power loss or pressure drops. Anodized surfaces provide corrosion resistance for harsh environments.
- Vertical load holding in material handling systems
- Emergency stop positioning in assembly line fixtures
- Precision workholding in CNC machine tool changers
- Safety locking in foundry equipment during maintenance
- Position retention in automated warehouse stackers
Operational note:
Engage lock mechanism only when cylinder is fully retracted.
Requires weekly lubrication (ISO VG32 oil) through air line lubricator.
Avoid side-load forces exceeding 30N to prevent rod deformation.
Critical installation:
Must align locking mechanism orientation with gravity direction
(arrow marking on barrel indicates permitted load direction).
Use lock release tool (ASL-50 accessory) for manual override.
| Property | Property Value |
|---|---|
| sku | SULF50X75 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 75mm |
| Lock Position | Front Cover with Lock |
