Airtac SULF Front Locking Cylinder SULF63X100-S
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF63X100-S Front Lock Cylinder Specifications
- Model: SULF63X100-S
- Bore size: 63mm
- Stroke: 100mm
- Operating pressure: 0.1–1.0 MPa
- Locking mechanism: Mechanical wedge-type brake
- Mounting type: Standard ISO/VDMA front flange
- Cushioning: Adjustable pneumatic cushion
- Action type: Double-acting
- Temperature range: -10℃ to 80℃
- Seal material: NBR (nitrile rubber)
- Port size: G1/4 (standard), optional NPT1/4
- Weight: 3.2kg (excluding accessories)
- Dimensions: 250mm(L) × 63mm(W) × 63mm(H) (extended length)
- Rod thread: M16×1.5
- Piston speed: 50–800mm/s
- Brake response time: ≤0.2s
Heavy-duty lock cylinder with integrated mechanical brake system, designed for vertical load holding and emergency stop scenarios. Features wear-resistant chromium-plated rod and precision honed tube. The dual-safety design maintains position even during air supply interruption. Requires ISO VG32 hydraulic oil lubrication for optimal brake performance.
- Vertical lift mechanisms in automated assembly lines
- Safety locking in press machine rams
- Position retention in material handling robots
- Emergency stop systems for CNC tool changers
- Overhead conveyor pause control
- Align brake unit within 0.5° perpendicularity tolerance
- Maintain 0.5–1.0mm gap between brake surface and mounting base
- Use shock absorbers for loads exceeding 50kg
- Apply anti-vibration washers in high-frequency applications
Critical maintenance:
Replace brake pads every 500,000 cycles or when lock time exceeds 0.5s.
Always bleed air from both chambers before engaging lock mechanism.
| Property | Property Value |
|---|---|
| sku | SULF63X100-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
| Lock Position | Front Cover with Lock |
