Airtac SULF Front Locking Cylinder SULF63X40-S
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF63X40-S Front Lock Cylinder Technical Specifications
- Model: SULF63X40-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: 63mm
- Stroke: 40mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Locking force: 1,500N (max at 0.5MPa)
- Lock release pressure: ≥0.3MPa
- Mounting types: FA (Foot mounting), FB (Flange mounting), MP (Middle trunnion)
- Port size: G1/4 (ISO standard)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy barrel, CR-Steel piston rod
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP40 (Dust protected)
- Weight: 3.2kg (standard configuration)
- Dimensions: 223mm(L) × 63mm(W) × 63mm(H) (at mid-stroke position)
- Rod thread: M16×1.5 (male thread)
- Locking torque: 4.5N·m (recommended)
Industrial-grade locking cylinder featuring fail-safe mechanical position retention. The dual-chamber locking mechanism prevents unintended movement during power loss, with precision ground rod for smooth operation. Includes wear-resistant guide rings and integrated magnetic sensor slots (sensor not included). Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Vertical load holding in automated assembly lines
- Safety positioning in injection molding machines
- Workpiece clamping in CNC machining centers
- Emergency stop mechanisms in material handling systems
- Precision alignment fixtures in automotive manufacturing
Installation note:
Lock mechanism requires manual release during initial setup. Maintain 0.5mm minimum clearance between lock collar and mounting surface. Perform weekly lubrication checks in high-cycle applications (＞500 cycles/day).
| Property | Property Value |
|---|---|
| sku | SULF63X40-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <40mm> |
| Lock Position | Front Cover with Lock |
