Airtac SULF Front Locking Cylinder SULF63X800-S-TC
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF63X800-S-TC Front Lock Cylinder Specifications
- Model: SULF63X800-S-TC
- Type: Double-acting cylinder with mechanical front lock
- Bore size: 63mm
- Stroke: 800mm
- Operating pressure: 0.15–0.95 MPa
- Locking mechanism: Spring-assisted mechanical brake (auto-lock at stroke end)
- Mounting style: Front flange (ISO 15552 standard)
- Cushioning: Adjustable pneumatic cushion at both ends
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: ~4.8kg (excluding accessories)
- Dimensions: 892mm(L) × 80mm(W) × 80mm(H) (including lock unit)
- Rod thread: M20×1.5
- Port size: G1/8
- Piston rod material: Hard chrome-plated steel
- Protection rating: IP65 (standard wiper design)
Heavy-duty locking cylinder featuring fail-safe position retention during power loss. The integrated mechanical brake provides 3,500N holding force (at 0.5MPa) with zero backlash. Anodized aluminum barrel with corrosion-resistant coating ensures durability in harsh environments. Requires 5μm filtered air and regular lubrication (ISO VG32 recommended).
- Vertical load holding in automated assembly lines
- Clamping fixtures for CNC machining centers
- Safety brakes in material handling systems
- Position locking in automotive welding robots
- Mold securing in injection molding machines
Installation warning:
Lock engagement requires full piston extension - ensure proper stroke alignment.
Avoid side loads exceeding 10% of maximum thrust. Perform weekly brake clearance
checks (0.1-0.3mm gap recommended between lock sleeve and piston rod).
| Property | Property Value |
|---|---|
| sku | SULF63X800-S-TC |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 800mm |
| Lock Position | Front Cover with Lock |
