Airtac SULF Front Locking Cylinder SULF80X1350-S
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF80X1350-S Front Lock Cylinder Specifications
- Model: SULF80X1350-S
- Type: Double-acting cylinder with mechanical locking mechanism
- Bore size: Ø80 mm
- Stroke: 1350 mm (adjustable stroke available on request)
- Operating pressure: 0.15–1.0 MPa
- Locking force: 2,500 N (at 0.5 MPa)
- Locking method: Spring-activated mechanical brake
- Cushioning: Adjustable pneumatic cushion at both ends
- Port size: G3/8 (NPT1/2 optional)
- Piston rod material: Hard chrome-plated steel (SUS304)
- Cylinder tube: Anodized aluminum alloy
- Seal material: Heat-resistant NBR (+5℃ to +100℃)
- Ambient temperature: -20℃ to +80℃
- Weight: 18.7 kg (without accessories)
- Dimensions: 1,650mm(L) × 105mm(W) × 105mm(H) (full extension)
- Protection rating: IP67 (wipers included)
- ISO standard: 15552 (formerly ISO 6431)
Heavy-duty locking cylinder with fail-safe position retention capability, featuring dual-position sensor slots and corrosion-resistant construction. The integrated brake module provides instant mid-stroke locking within 0.3 seconds after air release. Requires 5-40μm filtered lubricated air (ISO 8573-1 Class 3.4.2).
- Automated warehouse vertical lift positioning
- Press machine safety interlock systems
- Wind turbine blade adjustment mechanisms
- Shipbuilding fixture positioning
- Robotic welding jig stabilization
Installation requirements:
Requires minimum 0.3 MPa unlocking pressure. Lubricate through air port with ISO VG32 oil
(3 drops/m³ air flow). Avoid vertical downward mounting orientations.
Maximum side load: 150N at full extension.
| Property | Property Value |
|---|---|
| sku | SULF80X1350-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 1350 mm |
| Lock Position | Front Cover with Lock |
