Airtac SULF Front Locking Cylinder SULF80X175
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF Series Front Locking Cylinder SULF80X175 Technical Details
- Model: SULF80X175
- Bore size: 80mm
- Stroke: 175mm
- Operation type: Double-acting with mechanical lock
- Working pressure: 0.1-1.0 MPa
- Locking force: 1,200N (at 0.5MPa)
- Ambient temperature: -20℃ to 80℃
- Port size: G3/8 (ISO standard)
- Cushioning: Adjustable buffer at both ends
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU hybrid seals
- Weight: 4.8kg ±2%
- Dimensions: 350mm(L) × 105mm(W) × 105mm(H) (retracted state)
- Lock release pressure: ≥0.15MPa
- Response time: ≤0.3s (lock engagement)
- Protection rating: IP54 (standard), IP67 optional
Heavy-duty locking cylinder featuring dual safety mechanisms with position retention capability even during air supply interruption. The integrated wedge-shaped lock provides zero-backlash holding force, with PTFE-impregnated guide rings reducing stick-slip effect. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Automated welding fixture position locking
- Press machine intermediate stroke suspension
- Elevator emergency braking systems
- Robotic arm tooling position retention
- Die casting machine mold securing
Installation protocol:
Mount in horizontal orientation only (±5° tolerance). Apply Molykote 111 paste
to locking mechanism during maintenance. Perform lock calibration every 50,000 cycles
using 0.5MPa test pressure.
| Property | Property Value |
|---|---|
| sku | SULF80X175 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 175mm |
| Lock Position | Front Cover with Lock |
