Airtac SULF Front Locking Cylinder SULF80X500-TC
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF Series Front Lock Cylinder SULF80X500-TC Technical Specifications
- Model Code: SULF80X500-TC
- Bore Size: Ø80 mm
- Stroke: 500 mm
- Operating Pressure: 0.1-1.0 MPa
- Locking Force: 1,570 N (at 0.5 MPa)
- Lock Type: Mechanical wedge lock (front position holding)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port Size: G1/8 (ISO standard)
- Ambient Temperature: -20℃ to +80℃
- Piston Speed: 50-750 mm/s
- Seal Material: NBR (Nitrile rubber)
- Body Material: Aluminum alloy (anodized surface)
- Rod Material: Chrome-plated carbon steel
- Weight: 5.8 kg (without accessories)
- Dimensions (L×W×H): 648mm × 96mm × 96mm (at mid-stroke position)
- Protection Class: IP40 (Dust protected)
- Mounting Options: Standard AF/MA series brackets
Heavy-duty locking cylinder with precision positioning capability, featuring instantaneous mechanical locking mechanism activated by air pressure release. The dual-piston design ensures stable clamping force distribution. Requires 40μm filtered compressed air with ISO VG32 lubricator oil mist (optional).
- Automated welding fixture position retention
- Vertical lifting platform emergency brake systems
- Injection molding machine core-pulling mechanisms
- Automotive assembly line jig stabilization
- Press tooling safety interlocks
Installation Guidelines:
Maintain horizontal orientation (±3° tolerance) for optimal locking performance.
Allow minimum 15mm clearance around cylinder body for heat dissipation.
Perform weekly lubrication checks during high-cycle operations (＞500 cycles/hr).
Critical Note:
Lock engagement requires minimum 0.3 MPa residual pressure.
Always install manual override release mechanism for maintenance safety.
| Property | Property Value |
|---|---|
| sku | SULF80X500-TC |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 500mm |
| Lock Position | Front Cover with Lock |
