Airtac TSAIM Cylinder with Guide Bracket TSAIM100X200S
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X200S Guided Rod Cylinder Specifications
- Model: TSAIM100X200S
- Type: Double-acting cylinder with integrated linear guide
- Bore size: Ø100mm
- Stroke: 200mm
- Operating pressure: 0.1–0.9 MPa
- Port thread: G3/8 (NPT1/2 optional)
- Cushioning: Adjustable hydraulic buffer
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Guide rail: Precision ground stainless steel
- Seal type: NBR/PU composite seals
- Temperature range: -10℃ to 80℃
- Weight: 12.5kg (with standard fittings)
- Dimensions: 650mm(L) × 210mm(W) × 180mm(H)
- Lubrication: Pre-lubricated (Grease Molykote 33M)
- Mounting: Front flange & rear foot (ISO 15552 standard)
Heavy-duty guided cylinder engineered for high moment load applications. Features dual hardened guide rails providing ±0.05mm repeatability, with integrated wear indicators. The anti-rotation design ensures precise linear motion under 2,500N lateral loads. Includes magnetic piston for position sensing compatibility.
- Vertical lifting systems in automotive assembly
- Precision glass panel handling robots
- Metal stamping press ejection mechanisms
- Heavy conveyor gate actuators
- Industrial press straightening fixtures
Installation note:
Ensure guide rail alignment within 0.2mm/m using laser level. Apply 25-35Nm torque
to mounting bolts in crisscross pattern. Maintain 1.5mm minimum clearance between
guide blocks and adjacent structures.
- Relubricate guide rails every 500km of travel
- Inspect buffer adjustment screws monthly
- Replace rod wipers after 1 million cycles
- Check guide block preload every 6 months
| Property | Property Value |
|---|---|
| sku | TSAIM100X200S |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
