Airtac TSAIM Cylinder with Guide Bracket TSAIM100X400S
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X400S Guided Rod Cylinder Specifications
- Model: TSAIM100X400S
- Type: Guided rod cylinder with integrated linear guide
- Bore size: 100mm
- Stroke: 400mm (±0.5mm tolerance)
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Front flange with precision alignment pins
- Port size: G1/2 (ISO228 standard)
- Piston rod material: Hard chrome-plated steel (HRC 45-50)
- Tube material: Anodized aluminum alloy (6063-T5)
- Guide rail: Precision ground stainless steel (SUS440C)
- Seal material: NBR with wear-resistant ring (DIN 3771)
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (Grease No. EA-L2501)
- Weight: 12.8kg ±2%
- Dimensions: 890mm(L) × 148mm(W) × 122mm(H)
- Protection rating: IP54 (standard wiper design)
Heavy-duty guided cylinder engineered for high moment load applications, featuring dual-axis linear guides with 4-row ball bearing system for enhanced rigidity. The T-shaped guide block design achieves 0.05mm/m alignment accuracy, eliminating side load deflection. Includes anti-vibration pads and overload protection grooves.
- Precision press-fit operations in automotive assembly
- Vertical lifting mechanisms for glass handling robots
- High-torque clamping fixtures for CNC machining centers
- Packaging line product orientation stations
- Semiconductor wafer transfer systems
Installation note:
Requires torque-controlled tightening (18-22 N·m for M10 mounting bolts).
Lubricate guide rails every 500km of travel using ISO VG32 hydraulic oil.
Avoid angular misalignment exceeding 0.2° during mounting.
| Property | Property Value |
|---|---|
| sku | TSAIM100X400S |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
