Airtac TSAIM Cylinder with Guide Bracket TSAIM100X450S
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X450S Guided Rod Cylinder Specifications
- Model: TSAIM100X450S
- Bore size: Ø100mm
- Stroke: 450mm
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-800 mm/s
- Ambient temperature: -20℃ to 80℃
- Buffer type: Adjustable hydraulic cushion (both ends)
- Mounting style: Basic type (MF1)
- Port size: PT1/4 (G1/4 optional)
- Rod end thread: M20×1.5
- Seal material: Polyurethane (NBR optional)
- Guide mechanism: Dual linear ball bearings
- Guide length: 300mm
- Lubrication: Pre-lubricated (ISO VG32 recommended)
- Weight: 5.8kg (excluding accessories)
- Dimensions: 830mm(L) × 136mm(W) × 136mm(H)
- Protection rating: IP54 (standard wiper)
- Repeat positioning accuracy: ±0.1mm
High-rigidity guided cylinder with integrated linear motion system, featuring dual-axis stabilization for moment load resistance up to 500N·m. The hardened steel piston rod (Cr-Mo alloy) with chrome plating ensures wear resistance in continuous operation. Precision ground guide rails provide ±0.01mm/m straightness accuracy.
- Vertical lifting mechanisms in automotive assembly
- Precision press-fit operations for electronics manufacturing
- Material transfer systems with side load requirements
- Packaging machinery with guided tooling paths
- Automated welding fixture positioning
Installation guidelines:
Requires parallel alignment within 0.2mm/m using precision level.
Lubricate guide rails every 500km of travel. Avoid lateral impact forces
exceeding 1,500N during operation. Mounting surface flatness ≤0.1mm.
Critical note:
When used in vertical applications, install external braking system
for safety. Maximum allowable eccentric load: 30% of thrust capacity.
| Property | Property Value |
|---|---|
| sku | TSAIM100X450S |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
