Airtac UCS Polyester Helix Hose UCS060040BK120MA3
2. High elasticity: Compact bend radius enables tight routing in confined spaces;
3. Kink-resistant design: Superior anti-kinking performance versus standard plastic tubing;
4. Outstanding shape memory: Endures repeated extension/retraction cycles without deformation;
5. Abrasion-resistant construction: Extended service life in high-wear industrial environments;
6. Low gas permeability: Minimizes leakage risks and fluid contamination;
7. Excellent solvent resistance: Eliminates environmental contamination from material degradation;
8. Minimal compression deformation: Maintains structural integrity under pressure;
9. Media compatibility: Suitable for compressed air and water systems.
Category: Spring Tube | Brand: AirTAC | Series: UCS Series
AirTAC UCS Polyester Spiral Tube UCS060040BK120MA3 Specifications
- Model: UCS060040BK120MA3
- Material: High-strength polyester with PU coating
- Inner Diameter: 6.0 mm ±0.3mm
- Outer Diameter: 40 mm (spiral peak-to-peak)
- Standard Length: 1200 mm (customizable up to 10m)
- Temperature Range: -40℃ to +120℃ (continuous use)
- Pressure Resistance: ≤1.2 MPa burst pressure
- Minimum Bend Radius: 40mm (dynamic)/25mm (static)
- Weight: 285g/m ±5% (approx. 342g for 1200mm unit)
- Compressed Length: 480mm (when fully collapsed)
- Color: Black (BK) with matte finish
- Flame Rating: UL94 V-2 compliant
- Certification: RoHS 2.0 compliant
Corrugated spiral tube with 360° shielding capability, featuring a unique "double helix" reinforcement structure for exceptional kink resistance. The MA3 variant incorporates anti-static treatment and UV stabilizers for outdoor applications. Internal surface smoothness Ra≤0.8μm ensures minimal airflow resistance.
- Pneumatic tool hose protection in automotive assembly lines
- CNC machine cable management systems
- Food-grade air supply lines (FDA-compliant material option)
- Robotic arm umbilical systems (100,000+ bend cycle rating)
- Hydraulic sensor wiring protection in agricultural machinery
Installation note:
For optimal performance, pre-stretch the tube by 8-10% before installation in high-vibration environments.
Use spiral-compatible clips every 300mm to prevent axial rotation. Avoid exposure to concentrated acids/alkalis >pH12.
| Property | Property Value |
|---|---|
| sku | UCS060040BK120MA3 |
| Inner Diameter | 4.0mm |
| Outer Diameter | <6.0mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (℃): -20~70 |
| Bend Radius | <38mm> |
| Material Length | 12M |
| Color | Black |
