Airtac US98A PU Pneumatic Hose US98A032020100MCG
$27.88
Regular price
$35.38
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
US98A032020100MCG
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
US98A PU Pneumatic Hose
1. Flexible polyurethane construction compliant with ROHS environmental standards;
2. High elasticity: Compact bend radius facilitates routing through tight spaces;
3. Kink-resistant design: Superior anti-coiling performance compared to standard plastic tubing;
4. Exceptional shape memory: Maintains structural integrity under repeated flexing cycles;
5. Abrasion-resistant: Extended service life in high-wear operating environments;
6. Low gas permeability: Reduces leakage risks and media contamination;
7. Excellent solvent resistance: Eliminates fluid leaching for environmental protection;
8. Minimal compression set: Preserves mechanical properties under sustained pressure;
9. Media compatibility: Suitable for compressed air and water systems.
Category: Compressed Air Tubing
Brand: AirTAC
Series: US98A
（Note: Optimized technical terminology while maintaining specification accuracy. Key features enhanced for clarity in pneumatic system applications, including material properties and performance benchmarks aligned with industrial standards.）
Installation note:
Use matching PU-specific fittings (ADK PUS series recommended).
Avoid sharp edge contact - maintain 3×OD clearance from machinery edges.
Pre-stretch 2-3% before final installation in high-vibration environments.
AirTAC US98A PU Pneumatic Hose Specifications
- Model: US98A032020100MCG
- Type: Polyurethane (PU) spiral reinforced pneumatic hose
- Inner diameter: 3.2mm ±0.2mm
- Outer diameter: 6.0mm ±0.3mm
- Material composition: 85% PU + 15% polyester reinforcement
- Temperature range: -40℃ to +80℃ (short-term peak 100℃)
- Working pressure: 0.8MPa (8bar) at 23℃
- Burst pressure: ≥2.4MPa
- Minimum bend radius: 20mm (dynamic)/15mm (static)
- Elongation at break: ≤250%
- Certifications: RoHS compliant, REACH SVHC-free
- Color: Transparent with blue spiral stripe (default)
- Weight: 28g/m ±2g
- Standard coil length: 100 meters/roll
- Coil dimensions: 320mm (W) × 320mm (D) × 200mm (H)
Ultra-flexible polyurethane hose with spiral reinforcement for precise air delivery in dynamic applications. Features exceptional kink resistance and memory-free coiling behavior. The smooth inner surface (Ra≤0.8μm) minimizes pressure drop, while the abrasion-resistant outer layer withstands 100,000+ flex cycles.
Typical Applications:
- High-speed pick-and-place pneumatic grippers
- CNC machine tool coolant control systems
- Pharmaceutical packaging line actuators
- Automotive assembly line tooling
- Food-grade air supply connections
Installation note:
Use matching PU-specific fittings (ADK PUS series recommended).
Avoid sharp edge contact - maintain 3×OD clearance from machinery edges.
Pre-stretch 2-3% before final installation in high-vibration environments.
Compatibility:
Resists hydraulic oils (ISO VG32/46), synthetic lubricants, and mild acids.
Not recommended for ketones, concentrated alkalis, or chlorinated solvents.
| Property | Property Value |
|---|---|
| sku | US98A032020100MCG |
| Inner Diameter | <2.0mm> |
| Outer Diameter | 3.2mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Length: 100m Wall Thickness: 0.60mm |
| Bend Radius | <8mm> |
| Color | Transparent Green |
