Airtac X-ABB Adapter - Double Male Thread Straight X-ABB0304
AirTAC X-ABB Double Male Thread Straight Connector X-ABB0304 Specifications
- Model: X-ABB0304
- Type: Double male thread straight through connector
- Thread specification: M5×0.8 male threads at both ends
- Material: Nickel-plated brass (C3604)
- Max working pressure: 1.5 MPa
- Burst pressure: ≥4.5 MPa
- Temperature range: -5℃ to 80℃
- Seal type: Integrated O-ring (NBR material)
- Flow rate: 300 NL/min (at 0.5 MPa)
- Surface roughness: Ra ≤1.6μm
- Weight: 12.5g ±0.3g
- Dimensions: 30mm(L) × 8mm(OD) × 8mm(OD)
- Compatible tube OD: Φ4mm (for push-in fittings)
- Protection rating: IP40 (standard environment)
Precision-machined pneumatic connector with dual corrosion-resistant layers, featuring laser-etched identification marks for traceability. The chamfered thread ends prevent O-ring damage during installation. Designed for 10,000+ connection cycles with ≤0.01 MPa pressure drop at max flow.
- Modular pneumatic circuit assembly
- Sensor mounting brackets in automation lines
- Vacuum system manifold connections
- Medical device pneumatic interfaces
- Robotic end-effector tooling
Installation note:
Apply 0.8-1.2 N·m torque during installation. Use thread sealant only on male threads (not on O-ring surfaces).
For gas applications, perform helium leak test at 0.6 MPa after installation.
| Property | Property Value |
|---|---|
| sku | X-ABB0304 |
