Airtac X-ABF Union - Female Thread with Lock Nut, Straight Terminal X-ABF1003
$5.23
Regular price
$12.73
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-ABF1003
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-ABF1003 Female Threaded Straight Connector with Locknut Specifications
- Model: X-ABF1003
- Type: Straight terminal connector (Bulkhead type)
- Thread standard: Metric (M5×0.8 internal thread)
- Locknut type: Hexagonal compression nut
- Material: Nickel-plated brass body
- Seal material: NBR O-ring (Black)
- Pressure range: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃ (with NBR seals)
- Proof pressure: 1.5 MPa
- Tube compatibility: Ø4mm (1/8") OD pneumatic tubing
- Surface treatment: Electroless nickel plating (5-8μm)
- Weight: 8.2g ±0.5g
- Dimensions: 18mm(L) × 10mm(W) × 10mm(H)
- Standards compliance: ISO 14743, JIS B8381
- Vibration resistance: 10–55Hz, 1.5mm amplitude
A through-panel pneumatic connector featuring dual sealing (thread & tube interfaces) for leak-free connections. The hexagonal locknut enables tool-free installation while maintaining 360° orientation adjustability. Nickel plating provides corrosion resistance in humid environments.
Typical Applications:
- Pneumatic control panel interface ports
- Modular equipment quick-connect systems
- Medical device gas line bulkhead connections
- Robotic arm pneumatic routing junctions
- Food machinery compressed air distribution
Installation protocol:
Apply 1.2–1.5 N·m torque during locknut tightening. Always insert tubing
until it bottoms out before tightening collar. Perform pressure test
at 0.8 MPa for 3 minutes post-installation.
Compatible accessories:
• X-TB04 series push-to-connect fittings
• X-M5F series manifold blocks
• X-PCF04 pneumatic tubing
• X-TB04 series push-to-connect fittings
• X-M5F series manifold blocks
• X-PCF04 pneumatic tubing
| Property | Property Value |
|---|---|
| sku | X-ABF1003 |
