Airtac X-ABF Union - Female Thread with Lock Nut, Straight Terminal X-ABF1003A
$5.23
Regular price
$12.73
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-ABF1003A
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-ABF1003A Connector-Locknut Internal Thread Straight Terminal Specifications
- Model: X-ABF1003A
- Type: Push-to-connect terminal with internal thread
- Body material: Nickel-plated brass (ISO 1179 compliant)
- Thread standard: M5×0.8 internal thread (Class 6H tolerance)
- Seal type: Integrated EPDM O-ring (FDA compliant)
- Pressure rating: 0.05–1.0 MPa (7-145 psi)
- Temperature range: -20℃ to 80℃ (continuous use)
- Tube compatibility: Φ4mm (5/32") OD polyurethane/nylon tubing
- Installation torque: 0.7–1.2 N·m (6.2–10.6 lb-in)
- Vibration resistance: ≤10–55Hz with 1.5mm amplitude
- Weight: 18.5g ±0.3g
- Dimensions: 19.8mm(L) × 14.2mm(W) × 14.2mm(H)
- Surface treatment: Electroless nickel plating (8–12μm thickness)
Precision-machined pneumatic terminal connector featuring tool-free tube insertion and 360° rotatable locknut. The dual-helix thread design ensures leak-proof connections in high-cycle applications. Compatible with ISO 15407-1 standard fittings.
Typical Applications:
- Modular pneumatic manifolds in assembly robots
- Vacuum pick-and-place systems
- Medical gas distribution panels
- Semiconductor wafer handling equipment
- Mobile hydraulic control units
Installation protocol:
Apply 2-3 drops of pneumatic oil on O-ring before assembly.
Tighten using calibrated torque wrench in two stages - 50% torque for initial alignment,
then full torque after 5-minute thermal stabilization.
| Property | Property Value |
|---|---|
| sku | X-ABF1003A |
