Airtac X-ABF Union - Female Thread with Lock Nut, Straight Terminal X-ABF802
AirTAC X-ABF802 Internal Thread Straight Through Terminal Specifications
- Model: X-ABF802
- Type: Straight-through terminal with internal thread & locknut
- Thread standard: PT/NPT/BSPP
- Thread size options: PT1/8, PT1/4, PT3/8, PT1/2
- Material:
- Body: Brass (CuZn39Pb3)
- Locknut: Stainless steel (SUS303)
- Seal material: NBR/FKM (Nitrile/Fluorocarbon rubber)
- Working pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 150℃ (with FKM seals)
- Surface treatment: Electroplated nickel (3-5μm thickness)
- Weight: 28g ±1g (for PT1/8 size)
- Dimensions:
- Length: 40mm (thread engagement section)
- Outer diameter: 12mm (hex body)
- Wrench size: 17mm (locknut)
- Vibration resistance: ≤50m/s²
- Certification: RoHS compliant
Precision-machined straight connector featuring dual sealing structure with O-ring and metal-to-metal contact. The tapered thread design ensures leak-proof connections in high-pressure pneumatic systems. Nickel plating provides corrosion resistance against water vapor and mild chemicals.
- Terminal connections in modular pneumatic manifolds
- Sensor mounting interfaces in robotic arms
- Lubrication line junctions in packaging machinery
- Vacuum system port adapters
- Cooling air line distribution in CNC equipment
Installation guidelines:
Apply 32-38 N·m torque during assembly. Use two wrenches simultaneously -
one to hold the terminal body (12mm hex) and another to tighten the locknut (17mm).
Avoid overtightening which may deform sealing surfaces.
- ISO 15407-1 compliant pneumatic circuits
- 6mm/8mm OD polyurethane tubing (with appropriate ferrules)
- Modular valve banks using G1/8 mounting patterns
| Property | Property Value |
|---|---|
| sku | X-ABF802 |
