Airtac X-AFD Swivel Adjustable Hex Port Connector X-AFD4
AirTAC X-AFD4 Rotatable Hexagon Port Adaptor (X-AFD Series)
- Model: X-AFD4
- Type: 360° rotatable hexagon manifold with 6 ports
- Thread standard: PT1/8 (BSPP) female threads
- Body material: Brass (CuZn39Pb3) with nickel plating
- Seal material: NBR (Nitrile rubber)
- Working pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Rotation torque: ≤0.5 N·m (recommended max)
- Leakage rate: ≤3 bubbles/min (ISO 6952 standard)
- Pressure test: 1.5 MPa (150% of max pressure)
- Protection rating: IP40 (non-weatherproof)
- Weight: 118±5g
- Dimensions: 30mm(W) × 30mm(D) × 40mm(H)
Multi-directional pneumatic fitting featuring tool-free rotation adjustment with positive locking mechanism. The hexagonal body allows 6-way connection possibilities with simultaneous flow distribution. Precision-machined with anti-vibration grooves and color-coded sealing rings (blue for air inlet, transparent for exhaust).
- Hand-tighten initially, then apply 1/4 turn with wrench (max 0.5Nm)
- Apply thread sealant ONLY on male threads (not on adaptor)
- Align arrows on collar with desired flow direction
- For vertical mounting: Position exhaust ports downward
- Modular pneumatic test benches
- Robotic end-effector tool changers
- CNC machine multi-axis actuator clusters
- Food packaging line diverters
- Semiconductor wafer handling robots
Maintenance note:
Rotate collar monthly to prevent seal adhesion. Replace O-rings every 50,000 cycles or 2 years.
Never use PTFE tape - particles may clog micro-valves downstream.
| Property | Property Value |
|---|---|
| sku | X-AFD4 |
