Airtac X-AFD Swivel Adjustable Hex Port Connector X-AFD8
AirTAC X-AFD8 Rotary Adjustable Six-Way Distributor Specifications
- Model: X-AFD8
- Type: Rotatable multi-port manifold
- Port configuration: 6 outlets (360° adjustable)
- Thread standard: PT1/8 (BSPP) female threads
- Material: Nickel-plated brass body, NBR seals
- Max operating pressure: 1.0 MPa
- Temperature range: -5℃ to 80℃
- Rotation torque: ≤0.3 N·m (manual adjustment)
- Flow capacity: 350 NL/min (at 0.5 MPa)
- Weight: 215g ±5g
- Dimensions: 56mm (Diameter) × 42mm (Height)
- Surface treatment: Electroless nickel plating (8-12μm)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Modular flow distribution unit featuring 360° rotatable outlets with positive-lock mechanism. Engineered for dynamic piping layouts requiring multiple directional changes, with leak-proof design maintained through 10,000+ rotation cycles. Compatible with pneumatic and low-viscosity fluid systems.
- Multi-axis pneumatic tool changers
- Modular assembly line distribution nodes
- 3D printer air-assisted cooling systems
- Mobile hydraulic test benches
- Semiconductor wafer handling equipment
Installation note:
Apply pipe sealant on male threads (DO NOT use Teflon tape).
For optimal performance, limit angular adjustment to ≤270° during
pressurized operation. Perform torque check every 500 rotations.
| Property | Property Value |
|---|---|
| sku | X-AFD8 |
