Airtac X-APBT Connector - Full Brass Thread Straight Tee X-APBT1003
$8.60
Regular price
$16.10
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APBT1003
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APBT1003 Full Brass Threaded Straight Tee Specifications
- Model: X-APBT1003
- Type: Equal tee with full copper body
- Thread standard: BSPP (G thread)
- Port size: 1/8" (PT1/8, G1/8)
- Material: Lead-free brass CW617N
- Surface treatment: Electro-nickel plated (5-8μm)
- Pressure rating: 0.05-1.0 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -5℃ to 120℃
- Weight: 18.5±0.5g
- Dimensions: 18mm(L) × 18mm(W) × 24mm(H)
- Thread engagement depth: 7.5mm±0.3mm
- Torque limit: 1.5-2.0 N·m during installation
- Certification: RoHS compliant
Precision-machined brass tee connector featuring triple-helix thread design for enhanced sealing performance. The hexagonal body allows tool-assisted installation with anti-vibration grooves to prevent loosening. Compatible with air, water, and non-corrosive fluids.
Typical Applications:
- Pneumatic system branch line distribution
- Coolant line splitting in CNC machines
- Hydraulic test bench configurations
- Industrial robotic arm pneumatic circuits
- Beverage dispenser fluid networks
Installation note:
Apply PTFE tape clockwise on male threads (2.5 wraps recommended).
Avoid overtightening - use torque wrench for 1.8N·m maximum.
Compatible with JIS B0203 and ISO 228-1 standards.
