Airtac X-APBT Connector - Full Brass Thread Straight Tee X-APBT1004
AirTAC X-APBT1004 Full Brass Threaded Tee Fitting Specifications
- Model: X-APBT1004
- Type: Equal tee with male threads (3-way)
- Material: Lead-free brass (CW617N)
- Surface treatment: Electroless nickel plating (5-8μm)
- Thread standards: PT/NPT/G available
- Port sizes: 1/8" (BSPP/BSPT/NPT equivalent)
- Pressure rating: 0.5-1.6 MPa (72-232 psi)
- Burst pressure: ≥4.8 MPa (696 psi)
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile) O-rings
- Weight: 28±2g
- Dimensions: 21mm (L) × 21mm (W) × 21mm (H)
- Thread engagement: 6 full turns minimum
- Certifications: RoHS compliant, ISO 1179-1 standard
Precision-machined brass tee connector with triple-directional flow control capability. Features corrosion-resistant nickel plating and leak-proof design with pre-installed seals. Internal bore maintains consistent 4.2mm diameter across all ports for minimal pressure drop. Compatible with air, water, and inert gases.
- Pneumatic system branching in automation equipment
- Coolant line distribution in CNC machines
- Vacuum system manifolds
- Instrumentation gas sampling systems
- Compressed air tool networks
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads (for non-sealed versions).
Tighten using 12mm open-end wrench on hex flats - do not exceed 15N·m torque.
Align flow direction arrows with primary supply line.
| Property | Property Value |
|---|---|
| sku | X-APBT1004 |
