Airtac X-APBT Connector - Full Brass Thread Straight Tee X-APBT1202
AirTAC X-APBT1202 Full Copper Threaded Tee Fitting Specifications
- Model: X-APBT1202
- Type: Equal tee with straight-through flow path
- Material: Lead-free brass (CuZn39Pb0.5) with nickel plating
- Thread type: BSPP (G) thread
- Thread size: 1/8" (PT1/8)
- Max working pressure: 1.5 MPa (217 psi)
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Temperature range: -20℃ to 120℃ (-4°F to 248°F)
- Surface roughness: Ra ≤1.6μm
- Weight: 48g ±2g
- Dimensions: 19.5mm (L) × 19.5mm (W) × 24.8mm (H)
- Thread engagement depth: 8.5mm
- Seal type: Metal-to-metal seal (requires additional sealant)
- Corrosion resistance: 96hrs neutral salt spray test compliant
Precision-machined brass tee connector with triple-port configuration for pneumatic system branching. Features corrosion-resistant nickel plating and precision threads for leak-free connections. The compact hexagonal body allows wrench tightening with 14mm AF (across flats) compatibility.
- Pneumatic manifold splitting in automation equipment
- Air tool pressure line distribution
- Compressed air system instrumentation branches
- Vacuum system T-connections
- Industrial robot end effector air circuits
Installation note:
Apply PTFE tape or liquid sealant (Loctite 577 recommended) to male threads.
Tighten with 1.5-2.0 N·m torque using 14mm wrench. Avoid overtightening
which may cause thread deformation. Maximum angular deviation: ±5° from axis.
| Property | Property Value |
|---|---|
| sku | X-APBT1202 |
