Airtac X-APBT Connector - Full Brass Thread Straight Tee X-APBT1203
AirTAC X-APBT1203 Full Brass Threaded Tee Fitting Technical Details
- Model: X-APBT1203
- Type: Equal Tee (Straight Thread)
- Material: Lead-free brass (CW617N)
- Surface Treatment: Electroless nickel plating (5-8μm)
- Thread Standard: BSPP (G thread) / NPT optional
- Port Size: 1/8" (M5×0.8 metric thread available)
- Pressure Rating: 0.3-1.5 MPa (43.5-217.5 PSI)
- Temperature Range: -20℃ to 120℃
- Flow Coefficient (Cv): 0.15
- Weight: 28g ±2g
- Dimensions: 22mm(L) × 18mm(W) × 18mm(H)
- Seal Compatibility: Works with PTFE tape or liquid thread sealant
- Certification: RoHS compliant, REACH SVHC-free
Precision-machined brass tee connector with triple-directional flow paths, featuring corrosion-resistant nickel plating for extended service life in humid environments. The 60° tapered thread design ensures leak-free connections without damaging tube ends. Optimized internal bore geometry minimizes pressure drop across all ports.
- Pneumatic circuit branching in automation equipment
- Coolant line distribution in CNC machining centers
- Vacuum system manifolds for pick-and-place robots
- Compressed air networks in automotive service stations
- Hydraulic test bench plumbing systems (low-pressure)
Installation guidelines:
Apply 1.5-2 wraps of PTFE tape clockwise on male threads.
Tighten to 12-15 N·m torque using backup wrench on hex flats.
Avoid cross-threading by hand-starting all connections.
| Property | Property Value |
|---|---|
| sku | X-APBT1203 |
