Airtac X-APBT Connector - Full Brass Thread Straight Tee X-APBT1204
AirTAC X-APBT1204 Full-Brass Threaded Tee Fitting Specifications
- Model: X-APBT1204
- Type: Equal tee fitting with straight-through flow
- Thread standard: BSPP (G-thread) / NPT optional
- Port size: 1/8" (DN6)
- Material: Lead-free brass (CuZn39Pb3)
- Surface treatment: Electro-nickel plated (5-8μm)
- Weight: ~30g (including packaging)
- Dimensions: 20mm(L) × 20mm(W) × 25mm(H)
- Temperature range: -20℃ to 120℃ (continuous use)
- Max working pressure: 1.5 MPa (15 bar)
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Fluid compatibility: Air, inert gases, water (non-corrosive media)
- Certification: RoHS compliant
- IP rating: IP40 (as installed)
Precision-machined brass tee connector featuring triple-directional 55° tapered threads for leak-resistant sealing. The hexagonal body design allows wrench tightening (12mm AF) while maintaining compact dimensions. Internal bore maintains consistent 4mm diameter across all ports to minimize pressure drop.
- Branch line creation in pneumatic control systems
- Modular assembly of automation equipment manifolds
- Coolant line distribution in CNC machinery
- Vacuum system plumbing for semiconductor tools
- Medical gas line installations (oxygen/nitrogen distribution)
Installation protocol:
Apply thread sealant only on male threads (PTFE tape recommended).
Tighten to 8-10 N·m torque maximum. Perform pressure test at 1.25×
working pressure after assembly. Avoid cross-threading - hand-tighten
minimum 2.5 turns before final torque application.
| Property | Property Value |
|---|---|
| sku | X-APBT1204 |
