Airtac X-APBT Connector - Full Brass Thread Straight Tee X-APBT401
$5.28
Regular price
$12.78
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APBT401
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APBT401 Full Brass Threaded Tee Fitting Specifications
- Model: X-APBT401
- Type: Brass Equal Tee with Straight Threads
- Material: Lead-free brass (CuZn39Pb3) with nickel plating
- Thread Standard: BSPP (G), NPT, or Metric options
- Port Sizes: 1/8" (G1/8), 1/4" (G1/4), 3/8" (G3/8) available
- Pressure Rating: 0.05-1.5 MPa (7-217 PSI)
- Temperature Range: -20℃ to 120℃ (-4℉ to 248℉)
- Surface Finish: Electrostatic epoxy coating (standard black)
- Leakage Rate: ≤0.1 NL/min under 0.5 MPa
- Certifications: RoHS compliant, ISO 1179-1 standard
- Weight: 48g (G1/8 size)
- Dimensions: 30mm (L) × 30mm (W) × 30mm (H) ±0.5mm
Precision-machined brass tee connector with triple-directional flow paths, featuring 60° inverted seat design for secure tubing retention. Anti-vibration grooves enhance connection stability in high-frequency pneumatic systems. Compatible with nylon/polyurethane tubing (4-6mm OD).
Typical Applications:
- Pneumatic circuit branching in CNC machinery
- Compressed air distribution networks
- Vacuum system manifold connections
- Industrial robot end-effector air supply
- Packaging machine pneumatic loops
Installation tip:
Apply 2-3 wraps of PTFE tape on male threads clockwise.
Torque specification: 12-15 N·m for G1/8 size.
Avoid overtightening to prevent thread deformation.
| Property | Property Value |
|---|---|
| sku | X-APBT401 |
