Airtac X-APBT Connector - Full Brass Thread Straight Tee X-APBT402
$5.65
Regular price
$13.15
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APBT402
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APBT402 All-Copper Threaded Straight Tee Specifications
- Model: X-APBT402
- Type: Brass straight tee with parallel threads
- Material: Lead-free CW617N brass (RoHS compliant)
- Thread Standard: ISO 228 G1/8 (BSPP)
- Pressure Rating: 0.05-1.6 MPa
- Temperature Range: -20℃ to 120℃
- Fluid Compatibility: Air, water, inert gases (not for corrosive media)
- Surface Finish: Electroplated nickel coating (3-5μm)
- Leakage Rate: ≤0.1 mL/min at 0.5 MPa
- Weight: 28g ±0.5g
- Dimensions: 28mm(L) × 24mm(W) × 24mm(H)
- Torque Rating: 12-15 N·m installation torque
Precision-machined brass tee connector with triple-sealing design (thread + O-ring + metal-to-metal contact). Features anti-vibration grooves and 360° rotatable ports for flexible plumbing configurations. Includes built-in particle filtration channels to prevent clogging.
Typical Applications:
- Pneumatic circuit branching in automation equipment
- Coolant line distribution for CNC machines
- Low-pressure hydraulic test rig assemblies
- Beverage dispensing system plumbing
- Medical gas delivery systems (oxygen/nitrogen lines)
Installation protocol:
Apply PTFE tape clockwise on male threads (2.5 wraps recommended).
Avoid overtightening - use torque wrench for precise 14 N·m force.
Perform pressure test at 1.8 MPa after installation.
| Property | Property Value |
|---|---|
| sku | X-APBT402 |
