Airtac X-APBT Connector - Full Brass Thread Straight Tee X-APBT4M5
AirTAC X-APBT4M5 All-Copper Straight Tee Fitting Specifications
- Model: X-APBT4M5
- Type: Pneumatic straight tee fitting (equal distribution)
- Material: H59-1 lead-free brass (RoHS compliant)
- Thread type: Metric fine thread (M5×0.8)
- Port configuration: 3-way female threads (F/F/F)
- Tube compatibility: 4mm OD pneumatic tubing
- Pressure rating: 0.05-1.2 MPa
- Temperature range: -20℃ to 120℃
- Surface treatment: Electroplated nickel (8-12μm thickness)
- Weight: 9.5±0.3g
- Dimensions: 18mm (Hex width) × 18mm (Port-to-port length)
- Torque specification: 0.8-1.2 N·m
- Thread engagement: ≥3 full turns required
Precision-machined brass tee connector with triple sealing surfaces, designed for leak-free branching in compact pneumatic systems. Features corrosion-resistant nickel plating and 360° rotatable ports for flexible installation alignment. Compatible with air, inert gases, and vacuum applications.
- Modular pneumatic manifolds in factory automation
- Medical device gas distribution systems
- 3D printer pneumatic circuit branching
- Laboratory instrumentation air lines
- Robotic end-effector control circuits
Installation guidelines:
Use two wrenches during assembly - one to hold the base fitting and another to tighten the connecting component.
Apply thread sealant only on male threads, avoiding contamination of fluid pathways.
Maximum recommended tightening torque: 1.5 N·m.
| Property | Property Value |
|---|---|
| sku | X-APBT4M5 |
