Airtac X-APBT Connector - Full Brass Thread Straight Tee X-APBT601
$5.80
Regular price
$13.30
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APBT601
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APBT601 Full Brass Threaded Straight Tee Fitting Specifications
- Model: X-APBT601
- Type: Pneumatic straight tee connector
- Material: Lead-free brass (CuZn39Pb3)
- Thread type: Metric (M5×0.8) or BSPP (G1/8") optional
- Port configuration: Three-way equal diameter
- Pressure rating: 0.05-1.5 MPa (7-217 psi)
- Temperature range: -20℃ to 120℃
- Surface treatment: Electroplated nickel (5-8μm thickness)
- Thread tolerance: ISO 1179-1 standard
- Sealing type: Metal-to-metal sealing with optional PTFE tape
- Weight: 82g ±2g
- Dimensions: 20mm (L) × 20mm (W) × 20mm (H)
- Certifications: RoHS compliant, ISO 9001:2015
High-density brass tee connector with precision-machined threads, designed for stable branching in pneumatic systems. Features corrosion-resistant nickel plating and vacuum-tight sealing capability. Compatible with air, inert gases, and non-flammable hydraulic fluids.
Typical Applications:
- Air compressor distribution networks
- CNC machine tool pneumatic circuits
- Packaging machinery air line branching
- Industrial robot end-effector supply lines
- Laboratory gas chromatography systems
Installation guide:
Apply 1.5-2 wraps of PTFE tape clockwise on male threads.
Tighten to 12-15 N·m torque using backup wrench on hex base.
Avoid overtightening to prevent thread deformation.
| Property | Property Value |
|---|---|
| sku | X-APBT601 |
