Airtac X-APBT Connector - Full Brass Thread Straight Tee X-APBT602
AirTAC X-APBT602 Full Brass Threaded Tee Fitting Specifications
- Model: X-APBT602
- Type: Equal tee with full brass construction
- Thread standard: BSPP (G thread)
- Port size: 1/8" (G1/8)
- Material: Lead-free brass CW617N
- Surface treatment: Electroplated nickel (3-5μm)
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 120℃
- Proof pressure: 3.0 MPa
- Burst pressure: ≥6.0 MPa
- Weight: 28g ±2g
- Dimensions: 24mm(L) × 24mm(W) × 24mm(H)
- Port configuration: Three 1/8" female ports at 90° angles
- Seal compatibility: Works with PTFE tape or liquid thread sealant
- Compliance: RoHS 2.0 compliant
A precision-engineered fluid distribution component featuring triple-ported design with uniform internal flow channels. The hexagonal body allows secure wrench tightening (recommended torque 12-15Nm). Anti-corrosion nickel plating ensures durability in humid environments while maintaining electrical conductivity for grounding applications.
- Pneumatic system branch line connections
- Coolant line distribution in CNC machines
- Vacuum system manifolds
- Compressed air tool hookups
- Medical gas line assemblies
- Food-grade CO₂ distribution systems
Installation note:
Apply sealant to male threads only. Avoid overtightening - stop rotation when
fitting seats firmly. For gas applications, perform pressure decay test after installation.
| Property | Property Value |
|---|---|
| sku | X-APBT602 |
