Airtac X-APBT Connector - Full Brass Thread Straight Tee X-APBT6M5
$5.80
Regular price
$13.30
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APBT6M5
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APBT6M5 Full Brass Threaded Straight Tee Specifications
- Model: X-APBT6M5
- Type: Pneumatic straight tee connector
- Material: Lead-free brass (CuZn39Pb3)
- Thread Standard: Metric (M5×0.8)
- Port Configuration: 3-way equal diameter
- Pressure Range: 0-1.0 MPa (145 psi)
- Temperature Range: -20℃ to 120℃ (continuous use)
- Surface Treatment: Electro-nickel plated (8-12μm thickness)
- Seal Material: NBR (Nitrile O-rings)
- Weight: 22±1g
- Dimensions: 18mm (L) × 18mm (W) × 25mm (H)
- Flow Coefficient: Cv≈0.12
- Vibration Resistance: ≤10Hz/1.5mm amplitude
- Certification: RoHS compliant
Precision-machined brass tee connector with triple-layer nickel plating for enhanced corrosion resistance. Features 60° tapered thread seats for airtight sealing without additional paste. Internal flow channels optimized for minimal pressure drop (ΔP < 0.02MPa @ 0.5MPa).
Typical Applications:
- Branch line connections in pneumatic automation systems
- Modular assembly of pneumatic training kits
- Vacuum line distribution in packaging machinery
- Air brake system plumbing in commercial vehicles
- Laboratory pneumatic instrument clusters
Installation guidelines:
Apply 1.2-1.8N·m torque during assembly. Use thread sealant only on male threads.
Avoid overtightening - maximum rotation after hand-tight: 1.5 turns. Compatible with
tubing OD: 4mm (soft) or 6mm (hard).
| Property | Property Value |
|---|---|
| sku | X-APBT6M5 |
